Atelectronica 2016,Rohde & Schwarz(hall A1, booth 307) is presenting a full portfolio of test-and-measurement solutions. Among these is the new R&S NRPM OTA, allowing users in development and production to calibrate a transmit antenna’s output power and test its beamforming function using a simple test setup.
The company’s 5G test setup at electronica will consist of an R&S SMW200A vector signal generator and an R&S FSW85 signal and spectrum analyzer. This combination offers the flexibility and T&M functionality required to test solutions for candidate waveforms and new frequency bands, for example.
R＆S FSW85信号和频谱分析仪分析FMCW CHIRP信号高达2 GHz带宽，并覆盖24 GHz和79 GHz频带分配给汽车雷达的单个设备，不需要额外的外部转换器。
该公司的R＆S CMW500宽带无线电通信测试仪为汽车制造商提供了用于在信息娱乐系统上执行RF和音频测试的解决方案。该测试平台适用于开发，生产和服务，可用于模拟蓝牙，WLAN，LTE-A，WCDMA或GSM网络。
许多高度集成的组件都是为物联网（IoT）应用程序开发的，并配备了空气界面。R＆S CMW宽带无线电通信测试仪和R＆S RT-ZVC04探针可用于测试和监视，例如，在这些接口处的LTE传输的数据吞吐量和量解析度。
For measurements on highly integrated embedded designs, Rohde & Schwarz will present its R&S RTO2000 digital oscilloscope, which is designed for multi-domain applications. The oscilloscope allows developers to analyze the interaction between the various functional units of these complex designs.
The R&S RTO2000 and R&S RTE digital oscilloscopes can now be used in combination with the new, extremely low-noise R&S RT-ZP1X probe to carry out power measurements down to the millivolt range. This functionality is essential for measuring power integrity on embedded designs as used, for example, in IoT applications.
Also on display is the R&S Scope Rider, the first handheld oscilloscope with the functionality and touch and feel of a state-of-the-art lab scope. Its rugged design makes it perfect for mobile installation and maintenance work. The instrument features isolated input and communications interfaces. It meets CAT IV standards and can carry out measurements on low-voltage installation sources up to 600 V.
The R&S ESW EMI test receiver is designed for applications in manufacturers‘ EMI labs and in test houses. The instrument’s ultrafast FFT-based time domain scan delivers standard-compliant measurements in just seconds; these measurements can even be run with two CISPR detectors in parallel. The R&S ESW offers an exceptionally wide dynamic range and outstanding level accuracy. It can be used for EMI measurements starting from 2 Hz, such as those required in the A&D and automotive sectors.
The R&S ZNBT20 is the first true multiport network analyzer to offer up to 16 integrated test ports for operation up to 20 GHz. The high number of test ports makes it possible to perform signal integrity tests for transmission standards with high data rates. In combination with the R&S ZNBT-K20 option for extended time domain analysis, the R&S ZNBT can display eye diagrams, rise time, and skew.
